Description

• Hardware
  • High port density – RJ-45 connectors for up to 16 ports in a 1U housing
  • Laptop USB Console (LUC) – A dedicated USB port directly connects to a laptop for easy console operation
  • Two separate buses for one local console access and one remote over IP access
  • Two 10/100/1000 Mbps NICs for redundant LAN or two IP operation
  • Blade server support
  • Supports PS/2, USB, Sun Legacy (13W3) and serial (RS-232) connectivity
  • Local console provides PS/2 and USB keyboard and mouse support
  • Supports multiplatform server environments: Windows, Mac, Sun, Linux and VT100 based serial devices
  • Audio enabled
  • Virtual Media support lets you map DVD-CD-ROMs and other storage media to a remote server
  • Dual Power Supply
  • High video resolution – up to 1920 x 1200 @ 60Hz for local and remote sessions¹
  • Monitor and control up to 16 computers on a single level, or control up to 256 computers in a cascade².Note:
    1. 1920 x 1200 only supported by KA7166, KA7168, KA7169, KA7175, KA7176, KA7177, KA7170, and KA7178
    2. Cascade-compatible KVM Switches include the following: CS9134, CS9138, CS1308, CS1316, KH1508A, and KH1516A

• Management
  • Up to 64 user accounts
  • UP to 32 concurrent logins
  • End session feature – administrators can terminate running sessions
  • Event logging and Windows-based Log Server support
  • Critical system event notification via SMTP email; SNMP trap and Syslog support
  • Firmware upgradeable
  • Out-of-Band Access – Modem dial-in/dial-out/dial-back support
  • Adapter ID Function: Stores port information allowing administrators to relocate the servers to different ports, without having to re-configure the adapters and switches
  • Port Share Mode allows multiple users to gain access to a server simultaneously
  • Integration with ATEN CC2000 Management Software
  • Integration with ATEN CCVSR Video Session Recording Software¹
  • Supports ATEN KVM over IP Console Station (KA8270 / KA8280 / KA8278 / KA8288)
  • Power Association enables the switch’s KVM ports to be associated with ATEN’S PDUs power outlets for remote power management of the servers from the switch’s interface
  • Power Over the NET™ integration for remote power control, plus support for 3rd party power distribution units (PDUs)
  • Manage browser access methods (Browser, http, https)
  • IPv6 capableNote:
    1. Supports recording computer operations accessed via remote sessions

• Easy-to-Use Interface
  • Local Console, browser-based, and AP GUIs offer a unified multilanguage interface to minimize the user training time and increase productivity
  • Multiplatform client support (Windows, Mac OS X, Linux, Sun)
  • Multi-browser support: Edge, Chrome, Firefox, Safari, and Opera
  • Browser-based UI in pure Web technology allows administrators to perform administrative tasks without pre-installed Java software package required
  • Supports web-friendly KVM-over-IP access with HTML5 WebClient viewer – users can remotely access all the connected servers and PCs without Java or browser plug-in installation
  • Magic Panel – a special hideaway control panel with configurable function icon
  • Full-screen or sizable and scalable Virtual Remote Desktop
  • Panel Array Mode available to both local console operators and remote access users
  • Keyboard/Mouse Broadcast – keyboard and mouse inputs can be duplicated on all the attached servers
  • Video syncing with the local console – local console monitor’s EDID information stored on the KVM Adapter Cables for display resolution optimization

• Advanced Security
  • High-grade security – supports TLS 1.3 and an embedded FIPS 140-2 certified OpenSSL cryptographic module (Certificate #4282)
  • Remote authentication support: RADIUS, LDAP, LDAPS, and MS Active Directory
  • Supports TLS 1.3 data encryption and RSA 2048-bit certificates to secure users log in from browser
  • Flexible encryption design allows users to choose any combination of DES, 3DES, AES, RC4, or Random for independent KB/Mouse, video, and virtual media data encryption
  • IP/MAC Filter for enhanced security protection
  • Configurable user and group permissions for server access and control
  • Automated CSR creation utility and third party CA certificate authentication

• Virtual Media
  • Virtual media enables file applications, OS patching, software installation and diagnostic testing
  • Works with USB enabled servers in operating system and BIOS level
  • Support DVD/CD drives, USB mass storage devices, PC hard drives and ISO images

• Virtual Remote Desktop
  • Video quality and video tolerance can be adjusted to optimize data transfer speed; monochrome color depth setting, threshold and noise settings for compression of the data bandwidth in low bandwidth situations
  • Full screen video display or scalable video display
  • Message Board for communication among remote users
  • Mouse DynaSync™ – automatically synchronizes the local and remote mouse movements
  • Keyboard pass through support
  • Exit Macros support
  • On-screen keyboard with multilanguage support
  • BIOS-level access
