I/O Ports
I/O Ports 24 RJ-45 10/100/1000 ports,2 SFP+ 10GbE ports 2 10GBASE-T ports
Memory and Processor
Memory 1GB DDR3; 512MB NAND flash
Processor Single Core ARMv7 Cortex-A9 @800MHz
Packet buffer size 1.5 MB
Dimensions And Weight
Weight (metric) 3.9 kg
Product Dimensions (metric) 350.5 x 442.5 x 43.95 mm
Performance
Throughput (Mpps) 95 Mpps
switching capacity 128 Gbps
Electrical Characteristics
Maximum power rating 100-127V: 60W 200-220V: 80W
Idle power 100-127V: 30W 200-220V: 40W
Warranty
Warranty 5 Years

The Aruba Instant On 1960 24G 2XGT 2SFP+ Switch is part of the Aruba Instant On 1960 Series, designed to deliver high performance, ease of management, and flexibility for small to medium businesses. Here are its key features:

1. Hardware Specifications

  • Port Configuration:
    • 24x Gigabit Ethernet (1G) ports for connecting standard network devices.
    • 2x 10GBASE-T Ethernet ports supporting 10 Gbps data speeds, ideal for high-speed uplinks.
    • 2x 10Gbps SFP+ fiber ports for flexible fiber uplink options.
  • Switching Capacity: Offers a switching capacity of up to 128 Gbps, providing robust network throughput for high-demand environments.
  • Form Factor: Compact 1U rack-mountable design, fitting well within server racks for streamlined deployment.
  • Silent Operation: Fanless design ensures quiet operation, making it suitable for office environments where noise is a concern.

2. Performance and Scalability

  • Stackable Design: Supports stacking of up to four switches, allowing centralized management of multiple switches as a single entity.
  • Layer 2+ and Layer 3 Static Routing: Primarily a Layer 2 switch with some Layer 3 capabilities, including static routing, to enhance traffic management.
  • High Bandwidth Uplinks: The inclusion of 10G ports enables faster uplink speeds, essential for bandwidth-intensive applications and future-proofing the network.

3. Network Management

  • Cloud-Based Management: Fully managed through the Aruba Instant On mobile app and web portal, enabling remote management, monitoring, and configuration of the switch.
  • Intuitive User Interface: Simplified interface with guided workflows to help set up VLANs, trunking, and other configurations.
  • VLAN Support: Allows for network segmentation, enhancing security by isolating different types of traffic.
  • Access Control Lists (ACLs): Helps manage network access by defining rules that control network traffic and enhance security.

4. Enhanced Security Features

  • 802.1X Authentication: Provides port-based authentication, ensuring only authorized devices can access the network.
  • MAC Address Filtering: Restricts network access by MAC address, adding an additional layer of access control.
  • Encryption Protocols: Supports various encryption protocols to protect data as it moves across the network.

5. Reliability and Ease of Deployment

  • Zero-Touch Provisioning: Streamlines deployment by allowing automatic configuration updates during setup, reducing setup time and minimizing errors.
  • Limited Lifetime Warranty: Comes with a limited lifetime warranty, offering users peace of mind and reducing long-term maintenance costs.
  • Energy-Efficient: Complies with Energy Efficient Ethernet (EEE) standards, reducing power consumption during low traffic periods.
